Flail mower vineyard medium-heavy - MKP Series with Hydraulic Displacement
The GRAECUS MKP - H series mulchers are a medium-heavy type with a working width of 125 to 175 cm. The model has a lateral displacement of 20 to 35 cm. Their compact dimensions and sturdy construction have become popular among fruit growers. Electronically balanced rotor, forged hammers, lateral displacement and adjustable roller with wiper are some of their main features. It is an option to order knives instead of forged hammers. The MKP series is suitable for tractors with power from 20 to 40 hp.
Flail mower medium type MKP125-H
800g heat forged hammers to shred vegetation up to 5cm thick.
Cast iron gear box “COMER” Τ311 with free wheel 540 rpm.
SKF long life bearings.
Electronically balanced rotor.
Protective front bulk-heads.
Innovative construction of the linkage system offers more sideshift.
The vessel is equipped internally with two toothed blades for better shredding.
Height adjustable lateral skids.
Adjustable roller unit with mud scraper.
3 belt transmission with external tensioner.
Universal 3 points linkage cat. I-II(ø 19.0-22.0mm).
CE Safety Guard.
|Minimal tractor power:||20 HP|
|Dimensions and weight|
|Working width:||125 cm|
